Axial, centrifugal, EC, and DC fans with published airflow curves, sound data per octave band, and stock availability across three distribution hubs. Get spec sheets, bulk pricing, or a custom configuration quote in one request.
Each product line ships with full airflow-pressure curves, noise data, motor specs, and mounting dimensions. Select a category to view the catalog or request OEM integration details.
Propeller and tube-axial configurations from 100mm to 1250mm diameter. Available in AC, EC, and DC motor options with IP54/IP55 protection and optional ATEX-rated models for hazardous environments.
Forward-curved, backward-curved, and radial blade designs for medium-to-high static pressure applications. Belt-driven and direct-drive configurations, 200mm to 900mm impeller diameters.
Electronically commutated motor fans with 30-40% lower power consumption versus AC equivalents. ErP Lot 6 compliant. Integrated speed control via 0-10V, PWM, or Modbus.
Mixed-flow inline fans and positive pressure blowers for ducted ventilation, exhaust extraction, and process air supply. Circular and rectangular duct connections from 100mm to 630mm.
Electronically commutated motors eliminate the efficiency losses inherent in AC induction designs. At part-load conditions where fans operate 70-80% of the time, the energy savings compound further because EC motors maintain high efficiency across the speed range instead of dropping off below 50% load.
The following outcomes are representative of fan replacement and new installation projects completed between 2022 and 2025 across our three core application segments.
A 2,400 m2 colocation facility in Frankfurt replaced 48 AC axial condenser fans with EC equivalents rated at 8,500 CFM each. Post-installation monitoring over 12 months showed a 37% reduction in fan energy consumption (measured at the electrical panel), lowering annual fan power cost from EUR 142,000 to EUR 89,500. Fan noise at the property boundary dropped from 72 dB(A) to 61 dB(A), resolving a municipal noise complaint that had limited overnight cooling capacity.
An ISO Class 7 cleanroom expansion at a contract pharmaceutical manufacturer in New Jersey required 120 fan filter units (FFUs) with EC motors. Each FFU delivers 900 CFM at 250 Pa through HEPA filters with airflow uniformity within ±5% across the filter face. The EC motor variable speed control enabled the facility to maintain positive pressure cascade across four clean zones without manual damper adjustment, reducing commissioning time from 3 weeks to 4 days.
A poultry processing plant in Georgia installed 16 stainless steel (316L) centrifugal exhaust fans rated IP66 for washdown areas where chlorinated cleaning agents are used daily. The fans replaced carbon steel units that required recoating every 18 months due to corrosion. After 24 months of operation, the stainless housings showed no measurable material loss, eliminating the $38,000 annual recoating maintenance budget and reducing unplanned downtime by 120 hours per year.
Tell us the airflow rate, static pressure, voltage, and quantity. We send back a datasheet, price, and delivery window within one business day.
Request Specifications & Pricing
